In the Gendarmerie Commando Special Public Security Command, the "5th Term Frog Man Course" was successfully completed with the participation of 9 guest personnel from Albania and Montenegro within the scope of cooperation with friendly and allied countries.



[CemalPasha]

First UAV's of Turkish army via Cengiz Sogutlu

TAI Sahit Tactical UAV 'IHA-X1' (1992)

CL-89

TAI Keklik target drone (1995)

TAI Turna/Turna G target drone 'S-38' (1995)

GNAT 750 1997

1997-98/ EES- Doğan & Kırlangıç​

TAI Marti UAV (2003)

TAI Pelican UAV 'IHA-X2' (2003)

TAI Baykus tactical UAV (2003-2004)

TAI R-300 VTOL Combat UAV

R-300 has fully-autonomous flight including automatic take-off and landing capability.

Characteristics

• Length (m) : 6,10
• Rotor Diameter (m) : 5,95
• Payload Weight (kg) : 80
• MTOW (kg) : 325

Performance

• Endurance (hr) : 4+
• Service Ceiling (ft) : 10.000 (MSL)
• Datalink Range (km) : 200
• Max. Cruise Speed (kts) : 70

System Features

• Full HD EO/IR payloads
• Fixed or moving target tracking capability
• Fully autonomous operation
• Automatic take-off and landing
• High data rate digital datalink
• Remote Video Terminal option
• Easy-to-Maintain

Control Station Features

• STANAG 4586 compliant GCS
• Mission planning, management, simulation and playback capabilities
• Data recording capability
• User-frendly MMI
• External C4I Interface

Max.t/o weight: 85 kg.
Powerplant: Wankel/38 hp.
Mission speed: 90 kts.
Endurance: 120+ mns.
Max. altitude: 12000 ft.
Payload: EO/IR
Data link range: 50 km.
Launch/Recovery: Catapult/Parachute.

The composite platform, which can reacha maximum altitude of 12000 ft (ASL),
with 8 kg maximum payload capacity,is capable to carry both daylight and night camera and transfer
real-time video images up to 50 km.All the critical hardware and software of the system,
which has way point navigation and autonomous flight capabilities, have also been developed byTAI engineers.

ODTÜ (METU) Kelaynak (2003)

DTÜ (METU) Taktik (2003)

ITU ATA-4 & ATA-5 (2004)

Vestel Arı mini UAV & Vestel Efe mini (2005)

Global Teknik (GlobiHA) mini UAV 2005

ODTÜ (METU) GüvenTürk mini uav 2006

TAI Öncü (2007)

TAI Gözcü tactical UAV (2007)



[Musashi]

To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

Accept third party cookies



[Kadir93]

Foça Gendarmerie Commando School trainee.



[Faheka]

Foça Gendarmerie Commando School trainee.

View attachment 349359

More



[CemalPasha]

Coast Guard Command via Cengiz Sögütlü

Surface patrols are carried out by 52 patrol vessels and smaller craft. The most effective of these are 14 search-and-rescue vessels ||220 tons of Turkish design. Smaller 150 ton and 70 ton patrol boats of German design were nearing obsolescence in the mid 1990s. An ambitious construction plan foresaw a major strengthening of the service with eight new vessels of 350–400 tons and 48 ships of 180–300 tons.

5,673 Personnel (February 2016)
102 Coast Guard Boat
4 Search and Rescue Ships
13 helicopters
3 Planes

Coast Guard Corvettes​

​

Coast Guard Corvettes​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 88.60 m - 12.20 m - 5.40 m
Displacement Tonage	: 1750 Ton
Propulsion	: 6973 HPx2
Maximum Speed	: 22 Kts
Economic Speed / Range	: 15 Kts - 3000 nautical mile

TCSG DOST (SG 701)

TCSG GÜVEN (SG 702)

TCSG UMUT (SG 703)

TCSG YAŞAM (SG 704)

TYPE 80 Class Boats (total 19)​

​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 40.75 m - 7.05 m - 2.1 m
Displacement Tonage	: 195 Ton
Propulsion	: 2692 HPx2
Maximum Speed	: 25,5-27,5 Kts
Economic Speed / Range	: 13-20 Kts - 1000 nautical mile

Characteristics:
Displacement: 198 tons full load
Crew: 24
Weapons:
Guns: 1 x 40mm/70; 2 x 12.7mm MG.
Sensors:
Radars: Decca, navigation, two boats of this class received electro-optical sensor system.
Comments:
Enlarged version of SAR 33 class, built in Turkey

Boat's;

​

NUMBER	NUMBER	NUMBER
SG-80	SG-86	SG-92
SG-81	SG-87	SG-93
SG-82	SG-88	SG-94
SG-83	SG-89	SG-95
SG-84	SG-90	SG-96
SG-85	SG-91	SG-97

SAR 35 Class CG Boats (total 4)​

​

SAR 35 Class CG Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 36.6 m - 8.6 m - 2.7 m
Displacement Tonage	: 210 Ton
Propulsion	: 3200 HPx2
Maximum Speed	: 26 Kts
Economic Speed / Range	: 15 Kts - 517 nautical mile

Characteristics:
Displacement: 210 tons full load
Speed, Range: 26 knots, 450 miles at 24 kts.
Crew: 24
Weapons:
Guns: 1 x 40mm/70; 2 x 12.7mm MG.
Sensors:
Radars: Decca, navigation
Comments:
Enlarged version of SAR 33 class, built in Turkey

​

NUMBER

SG-71

SG-72

SG-73

SG-74

SAR 33 Class CG Boats (total 10)

SAR 33 Class CG Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 34.6 m - 8.6 m - 3.75 m
Displacement Tonage	: 180 Ton
Propulsion	: 3200 HPx2
Maximum Speed	: 27 Kts
Economic Speed / Range	: 15 Kts - 600 nautical mile

Characteristics:
Displacement: 180 tons full load
Crew: 24

Weapons:
Guns: 1 x 40mm; 2 x 12.7mm MG.

Sensors:
Radars: Decca, navigation

Comments:
The prototype of this class was designed by Erbil Sertel, a renowed Turkish naval engineer and built by Abeking & Rasmussen. The rest in Turkey. These boats were overhauled in Istanbul Shipyard.

​

NUMBER	NUMBER
SG-61	SG-66
SG-62	SG-67
SG-63	SG-68
SG-64	SG-69
SG-65	SG-70

Kaan 33 Class CG Boats (total 13 boat's)​

​

Kaan 33 Class CG Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 35.65 m - 6.7 m - 1.62 m
Displacement Tonage	: 113 Ton
Propulsion	: 3700 HPx2
Maximum Speed	: 45 Kts
Economic Speed / Range	: 40 Kts - 500 nautical mile

Characteristics:
Crew: 20

Weapons:
Guns: 1 x 20mm; 2 x 12.7mm MG.

Sensors:
Radars: Navigation

Comments:
Enlarged version of Kaan 29 class, designed by the same shipyard. The deliveries have started in 2004 and ended in May 20011. Further 7 will be delivered.

Remote-controlled stabilized machine gun platform STAMP, developed by Turkish defense contractor Aselsan is installed on TCSG-307, TCSG-308 and TCSG-312

KAAN 33 CLASS​

​

NUMBER	NUMBER	NUMBER
SG-301	SG-302	SG-303
SG-304	SG-305	SG-306
SG-307	SG-308	SG-309
SG-310	SG-311	SG-312
SG-313

Kaan 29 Class CG Boats (total 12)​

​

Kaan 29 Class CG Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 31.15 m - 6.7 m - 1.42 m
Displacement Tonage	: 97 Ton
Propulsion	: 3700HPx2
Maximum Speed	: 45 Kts
Economic Speed / Range	: 35 Kts - 500 nautical mile

Characteristics:
Crew: 13

Weapons:
Guns: 3 x 12.7mm

Sensors:
Radars: Navigation

Comments:
These boat are enlarged version of the Kaan 15 class interceptor boats. These boats are constructed to an indigenous design by the private Yonca/Onuk shipyard that built all the Kaan class boats used by Turkish Coast Guard and Navy.

First boat entered service in December 2000 and the last one in 2004. The tenth boat of the original contact was enlarged to Kaan 33 class.

​

NUMBER	NUMBER	NUMBER
SG-101	SG-102	SG-103
SG-104	SG-105	SG-106
SG-107	SG-108	SG-109

Kaan 19 Class CG Boats (total 10)​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 22.55 m - 4.76 m - 1.33 m
Displacement Tonage	: 38,8 Ton
Propulsion	: 1620 HPx2
Maximum Speed	: 58 Kts
Economic Speed / Range	: 45 Kts - 350 nautical mile

Characteristics:
Crew: 5

Sensors:
Radars: Navigation

Comments:
These boats are slightly enlarge version of Kaan 15 class interceptor boats. Made of composite materials.

The first Boat TCSG-19 was build according to a R&D contract signed between Turkish Coast Guard Command and Yonca-Onuk Shipyard. The prototype was tested in 2006 and final purchase order was be given after the successful termination of the tests.

KAAN 19 CLASS​

​

NUMBER	NUMBER
SG-19	SG-24
SG-20	SG-25
SG-21	SG-26
SG-22	SG-27
SG-23	SG-28

Kaan 15 Class CG Boats (total 18)​

​

Kaan 15 Class CG Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 15.4 m - 4.04 m - 1 m
Displacement Tonage	: 18.7 Ton
Propulsion	: 2300 HPx2
Maximum Speed	: 54 Kts
Economic Speed / Range	: 35 Kts - 350 nautical mile

Characteristics:
Crew: 4

Sensors:
Radars: Navigation

Comments:
These boats are built to an indigenous design by a private Turkish Yonca/Onuk shipyard. The prototype boat made 55,6 knots on trials.
First boat was handed to the Coast Guard in September 1998 and the last one in 2002. Like all Kaan class boats these are made off advanced composite materials.

​

NUMBER	NUMBER	NUMBER
SG-1	SG-7	SG-13
SG-2	SG-8	SG-14
SG-3	SG-9	SG-15
SG-4	SG-10	SG-16
SG-5	SG-11	SG-17
SG-6	SG-12	SG-18

Search And Rescue Boats​

​

Search And Rescue Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 19.45 m - 6.54 m - 1.1 m
Displacement Tonage	: 33.6 Ton
Propulsion	: 1200 HPx2
Maximum Speed	: 33 Kts
Economic Speed / Range	: 14 + Kts - 300 nautical mile

Search and Rescue Vessel 1906 “TCSG 901”, “TCSG 902”​

As part of an agreement between the European Union and the International Organization for Migration (IOM), Damen Shipyards Group has delivered two SAR 1906 vessels to the Turkish Coast Guard. The two vessels – the first to be delivered in what is a six-vessel contract – will be mobilised in refugee and migrant rescue operations.
Fabricated with an aluminium hull and a composite wheelhouse, the vessel’s light weight means that it can combine speeds of up to 33 knots with efficient fuel consumption.
A crucial aspect of the 19-metre long vessel is its attention to safety. The hull has been adapted from Damen’s Axe Bow technology which provides the seakeeping capabilities to operate in all weathers and sea states. Moreover, the engines and on-board equipment have been designed to continue operating even after the vessel has capsized.

CG Safety/Security Boats​

​

CG Safety/Security Boats​

Basic Specifications​

Dimensions (Length-Width-Draft)	: 13 m - 4 m - 1 m
Vessel	: Aliminium
Engine Power	: 550 HPx2
Maximum Speed	: 35 Kts

Control Boats​

​

Mobile Radars


General features
TYPE-1 Mobile Radar
Vehicle Model: Mercedes Sprinter
Duty Period : 24 Hours
Radar Range: 48 nautical miles
Communication : 2 Vhf (Aselsan 4031)


TYPE-2 Mobile Radar
Vehicle Model: IVECO Daily
Duty Period : 24 Hours
Radar Range: 48 nautical miles
Communication : 1 Vhf (Aselsan 4900)

Aircraft

Plane's

3 CASA CN-235

Helicopter

14 Agusta-Bell AB-412



[morris]

According to Temel Kotil, the general director of the Turkish aircraft manufacturer Turkish Aerospace Industries (TUSAŞ), the TF-X fighter's engine power will be 1.5 times that of the F-35, the prototype assembly will be completed in 2022, and the first flight is scheduled for 18 March 2023.



[CemalPasha]

Personnel of the 191st Fleet who served at the Aviano base in Italy within the scope of the NATO Joint Forge mission after the crises in the Balkans

20 July 2000



[CemalPasha]

Army Border Trooper equipped with biological protective suit and MKEK G3A3 7.62mm service rifle during a joint training with the Georgian Border Guard near Turkey-Georgia border. Via Deno



[CemalPasha]

Army Border Trooper equipped with biological protective suit and MKEK G3A3 7.62mm service rifle during a joint training with the Georgian Border Guard near Turkey-Georgia border. Via DenoView attachment 350634

More

Turkey-Georgia Border Units Exchange Exercise



[Faheka]

Images of the ongoing operations in northern Iraq.

To view this content we will need your consent to set third party cookies.
For more detailed information, see our cookies page.

Accept third party cookies



[CemalPasha]

M113T2 armoured field combat control vehicles, one with the NBC filtration unit on top during the field drills of 8th Mechanized Infantry Brigade in Tekirdağ region, Northwestern Turkey. Via DENO

M113T2 armoured ATGM carrier with BGM-71 TOW missile and M2 Brownig 12.7mm machine gun during field drills of the 8th Mechanized Infantry Brigade in Tekirdağ region, Northwestern Turkey.



[CemalPasha]

A new vehicle spotted of Turkish army during NATO Toxic Trip-2021 Aircraft rescue and firefighting vehicle

Volkan Lion Class ARFF 6X6​



[Faheka]



[CemalPasha]

Bayraktar Mini UAV used by border troops, Iran border.

Assuva Proton Elic RB-I M-3 used in the detection of underground tunnels and caves, Iranian border.

Assuva is Turkish Defence Company making Underground imagining, Area scanning devices & UAV's for underground-cave-area imagining. Also has unieq devices for military purposes like above.

Defence products:

Proton Elic RB-I M-3​

Proton Elic RB-I M-4​

Proton Elic RB-128 UAV​



[CemalPasha]

The holographic sight that Turkish firm Fotoniks produces under license. Via Aybars

Other products of Fotoniks

SINGLE PERSONNEL SYSTEMS

PLATFORM INTEGRATED SYSTEMS

UNIT LEVEL SYSTEMS

Turkish Defence firm Transvaro manufactures sublicense eotech hws.

Other products of Transvaro

HPEM SYSTEMS​

UAV DETECTION & DEFENCE SYSTEMS​

GIMBALS​

SNIPER DETECTION SYSTEMS​

MULTI SENSOR SURVEILLANCE SYSTEMS​

NIGHT VISION SIGHT & ATTACHMENTS​

NIGHT VISION SIGHT & ATTACHMENTS​

THERMAL IMAGING DEVICES​

BORDER SECURITY​

TACTICAL PRODUCTS​
