Tech Data Daring Class - Type 45 Destroyer

Discussion in 'Military Tech Data' started by Jack-Sparrow, Dec 17, 2015.


  1. Jack-Sparrow United Kingdom

    Jack-Sparrow Mi Lance corporal MI.Net Member

    Messages:
    43
    Likes Received:
    31
    Trophy Points:
    18
    [​IMG]

    Following data source wikipedia

    Name: Type 45 destroyer
    Builders: BAE Systems Maritime – Naval Ships
    Operators: Royal Navy
    Preceded by: Type 42
    Cost: Over £1,050M per ship inc R&D
    Planned: 6
    Completed: 6
    Active: 6

    General characteristics
    Type: Guided missile destroyer
    Displacement: 8,000[3] to 8,500 t (8,400 long tons; 9,400 short tons)
    Length: 152.4 m (500 ft 0 in)
    Beam: 21.2 m (69 ft 7 in)
    Draught: 7.4 m (24 ft 3 in)
    Installed power:
    • 2 × Rolls-Royce WR-21 gas turbines, 21.5 MW (28,800 shp) each
    • 2 × Wärtsilä 12V200 diesel generators, 2 MW (2,700 shp) each
    Propulsion:
    • 2 shafts integrated electric propulsion(IEP) with
    • 2 × Converteam electric motors, 20 MW (27,000 shp) each
    Speed: In excess of 30 kn (56 km/h; 35 mph)[8]
    Range: In excess of 7,000 nautical miles(13,000 km) at 18 kn (33 km/h)
    Complement: 191[9] (accommodation for up to 235)
    Sensors and
    processing systems:
    • SAMPSON multi-function air tracking radar (Type 1045)
    • S1850M 3-D air surveillance radar (Type 1046)
    • Raytheon Integrated Bridge and Navigation System
    • 2 × Raytheon AHRS INS
      (MINS 2)
    • 2 × Raytheon I-band Radar
      (Type 1047)
    • 1 × Raytheon E/F-band Radar
      (Type 1048)[10]
    • Ultra Electronics Series 2500 Electro-Optical Gun Control System (EOGCS)
    • Ultra Electronics SML Technologies radar tracking system
    • Ultra Electronics/EDO MFS-7000 sonar
    Electronic warfare
    & decoys:
    • UAT Mod 2.0 (2.1 planned)[12]
    • AN/SSQ-130 Ship Signal Exploitation Equipment (SSEE) Increment F cryptologic exploitation system [13]
    • Seagnat
    • Naval Decoy IDS300
    • Surface Ship Torpedo Defence
    Armament:
    • Anti-air missiles:
      • Sea Viper air defence system
      • 1 × 48-cell Sylver A50 VLS, for a combination of 48:
        • Aster 15 missiles (range 1.7–30 km)
        • Aster 30 missiles (range 3–120 km)
    • Anti-ship missiles:
      • 2 × quad Harpoon launchers
    • Guns:
      • 1 × BAE 4.5 inch Mk 8 naval gun
      • 2 × Oerlikon 30 mm guns
      • 2 × Phalanx CIWS
      • 2 × miniguns
      • 6 × general purpose machine guns
    Aircraft carried:
    • 1–2 × Lynx HMA8, armed with:4 × Sea Skua anti ship missiles, or
      • 2 × anti submarine torpedoes
    • or
    • 1 × Merlin HM1,[15] armed with:
      • 4 × anti-submarine torpedoes
    Aviation facilities:
    • Large flight deck
    • Enclosed hangar

    Bombardier likes this.
  2. Bombardier

    Bombardier Admin & Arbiter Staff Member Site Admin

    Messages:
    4,208
    Likes Received:
    1,117
    Trophy Points:
    138
    The ships of the Daring Class Type 45 Destroyer
    All built by BAE Systems Surface Ships


    HMS Daring Crest.jpg
    Daring D32 - Launched on 28 March 2003

    Dauntless D33 - Launched 26 August 2004

    hms diamond crest.JPG
    Diamond D34 - Launched 25 February 2005

    hms dragon crest.jpg
    Dragon D35 - Launched 19 December 2005

    hms defender crest.jpg
    Defender D36 - Launched 31 July 2006

    hms durcan crest.jpg
    Duncan D37 - Launched 26 January 2007
