Drone_pilot

AS 90 155mm - Self Propelled Howitzer

First delivered to the British Army in 1993, the AS90 equips 5 field regiments, replacing the Abbot and M109. AS90 is equipped with a 155mm gun which fires the NATO L15 unassisted projectile out to a range of 24.7 kms. Fitted with autonomous navigation and gun laying system (AGLS), AS90 can work independently of external sighting references. Central to the system is an inertial Dynamic Reference Unit (DRU). All main turret functions are controlled by a Turret Control Computer (TCC). This technology allows AS90 a burst fire capability of 3 rounds in 10 seconds.

Image taken from [url=http://anzacsteel.hobbyvista.com/Armoured%20Vehicles/as90ph_1.htm]anzacsteel[/url] visit site for more info/images
Click to expand...
Zofo
That is a monster! I presume that "the NATO L15 unassisted projectile " means shell?!

Edited because I just saw that shovel tacked onto the side of the vehicle - it looks as useful as an ashtray on a motorbike on that bit of kit - useful perhaps only for a shove recce!

Drone_pilot
That is a monster! I presume that "the NATO L15 unassisted projectile " means shell?!
Click to expand...

yes it's a shell unassisted as opposed to RAP Rocket assisted projectile.

  • Crew 5;
  • Length 9.07m:
  • Width 3.3m;
  • Height 3.0m overall;
  • Armour 17mm;
  • Calibre 155mm;
  • Range (39 cal) 24.7 kms (52 cal) 30 kms;
  • Rate of Fire 3 rounds in 10 secs (burst) 6 rounds per minute (intense) 2 rounds per minute (sustained);
  • Secondary Armament 7.62mm MG;
  • Ammunition Carried 48 x 155 mm projectiles and charges (31 turret & 17 hull);
  • Engine turbo-charged V8 diesel 600hp;
  • Max Speed 53 kph; Road Range 420 kms.
